Cosen SH-700DM CE Semi Automatic Mitre Cutting Bandsaw

Name: Cosen SH-700DM CE Semi Automatic Mitre Cutting Bandsaw – Double Mitre
Brand: Cosen
SKU: SAWB-0-6700

Large double mitre bandsaw

POA Excludes GST. Configuration and freight quoted with your enquiry.

NZ Prepared, installed and supported nationwide by Scott Machinery.

Blade speed range 20 - 100 m/min

Blade size 5790 x 41 x 1.3mm

Bundle height 450mm

Bundle width 700mm

NZ owned Since 1989

Industry people Practical machine advice

Auckland + Christchurch Two support hubs

Nationwide support Installation, training & service

Parts & accessories Large local range

Product overview

About this machine.

Established in 1976, Cosen Saws has become a global leader in industrial band saw manufacturing, offering over 140 models in horizontal, vertical, and miter-cutting configurations. Their machines are available in manual, semi-automatic, and fully automatic forms, catering to a wide range of cutting needs. With cutting capacities ranging from 200 mm to 2200 mm, Cosen's band saws are designed to handle materials such as steel, titanium, chromium, and silicon, serving industries including construction, automotive, aerospace, and wind power generation. Notably, Cosen was recognized as the No. 1 Sawing Equipment Brand by U.S. Metal Center News in 2015, 2022, 2023, and 2024. With a reputation for great value for money, they have spent more than 27 years in maximizing efficiency and quality in every step of designing, engineering and manufacturing to assure customers of long-lasting performance. In addition to utilizing internationally recognised components such as Siemens of German, Telemecanique of France and NOK seals of Japan. Cosen has also earned ISO-9001 standards as well as CE designation and EMC to assure customers around the globe of absolute quality and reliability.

The Cosen SH-700DM CE bandsaw is an industrial use semi-auto single swivel head mitring bandsaw. It has large capacity and has hydraulic lifting of the saw frame and a full stroke hydraulic vice. These features enable semi-automatic operation to securely hold the work piece, cut, and return the saw frame to a pre-set work height. The large, heavy-duty trunnion and swivel 'n' lock mechanism allows for up to plus 60 or minus 45 degrees of mitring capability.

Features:

Quality Taiwanese Manufacturing
Saw can mitre cut both ways (Double Mitre) up to 60 degrees
HD pivot & locking system
Rigid bow & wide base construction
Hydraulic cylinder with semi automatic bow lift
Specially designed base for mitre cutting from -45 to straight to +60 degrees
Rigid guide arms mounted on extra wide precision ground dovetail slide
Two additional bearings to support blade from the top
Convenient operator control station
Precision feed rate & feed pressure control via dual valve system
Blade vibration dampener
Work height selector

Standard Accessories:

Infinitely variable blade speed control via frequency inverter
Hydraulic vertical clamping vice
Hydraulic blade tensioning device
Carbide blade guides
Power driven blade cleaning brush
Complete coolant system
Additional flushing hose for cleaning
Work height selector
Adjustable length stop
Infeed roller
Work light

Included Options By Scott Machinery

Full stroke hydraulic top clamp with twin guide supports
Variable vice pressure regulator
High efficiency IE2 electric motor

Optional Accessories:

Hydraulic powered chip conveyor
2m Heavy duty roller table ( max capacity 3000kg )
3m Powered roller table
Laser line (indent only, must be factory fitted)
Mist lubrication cutting system (indent only, must be factory fitted)

Safety features:

Motor start interlock
Latching emergency stop
Safety interlock switch on blade guard
Blade breakage detection

CE Conformity

Published data

Specifications

Scroll horizontally to compare models or capacities. Use these to shortlist. We’ll confirm the specification and configuration against the application.

Specifications for Cosen SH-700DM CE
Cosen	SH-700DM
Capacity	Straight	+/- 45deg	+ 60deg
Round capacity	450mm	450mm	300mm
Width capacity (WxH)	700 x 450mm	520 x 450mm	300 x 450mm
Blade speed range	20 - 100 m/min
Blade size	5790 x 41 x 1.3mm
Bundle height	450mm
Bundle width	700mm
Coolant pump	0.18kW (1/4hp) (120L)
Hydraulic pump	1.5kW (2hp) (45L)
Work height	750mm
Motor power	5.6kW (7.5hp), 3 Phase
Floor space (LxWxH)	2700 x 3150 x 2720mm
Weight	2400kg
Shipping	19m3, 2500kg
