Bodor C3 Series Laser Cutting Machines
3048x1524mm to 12200x2500mm cutting capacity models 3-6-12-20-30-60kW models
NZ Prepared, installed and supported nationwide by Scott Machinery.
Product overview
About this machine.
Bodor is a world leader in laser technology and holds the No.1 position in global sales volume. Offering a 5 year warranty on their 'Laser stack' which comprises the Laser Head, Laser Source, and Operating System, demonstrates Bodor's 'best-in-industry' confidence in the longevity of their product. Bodor have made a huge investment in the laser industry with their Dream Park Headquarters and manufacturing base, covering 250,000 square meters, setting the stage to be the world's largest production base for laser cutting equipment.
Features
- Bodor C Series are Medium Power Fiber Laser Cutting Machines
Description:
- 1. High-strength semi-hollow machine bed
- 2. High-strength aluminium alloy beam
- 3. Fully automatic focus
- 4. CE Certificate
Components:
- CNC control system: Bodor Thinker
- Display size: 21.5"
- Laser source: Bodor Power
- Laser cutting head: Bodor Genius
Machine video
See Bodor C3 Series in operation.
Watch the machine at work, then talk to Scott about the right configuration for your material, application and workflow.
Discuss your applicationPublished data
Specifications
Scroll horizontally to compare models or capacities. Use these to shortlist. We’ll confirm the specification and configuration against the application.| Technical specification | |||||
|---|---|---|---|---|---|
| Model | C3 (3.1) | C3 (4.0) | C4 | C6 | C12 |
| Working area | 3048 x 1524mm | 3048 x 1524mm | 4000 x 2000mm | 6100 x 2500mm | 12200 x 2500mm |
| Laser Power (kW) | 3/6/12/20 k/W | 3/6/12 k/W | 3/6/12/20 k/W | 6/12/20/30 k/W | 12/20/30/60 k/W |
| Positioning accuracy (mm/m) | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm | +/- 0.05mm |
| Re-positioning accuracy (mm) | +/- 0.03mm | +/- 0.03mm | +/- 0.03mm | +/- 0.03mm | +/- 0.03mm |
| Maximum Acceleration (g) | 1.5g | 2.5g | 1.5g | 1.5g | 1.5g |
| Maximum Linkage speed (m/min) | 120 m/min | 180 m/min | 110 m/min | 110 m/min | 110 m/min |
Talk to Scott Machinery
Is this the right machine for your work?
Tell us about the largest job, material and likely workload. We can confirm the fit — or point you to the model either side.
