Turret AHL-1860 Premium Quality Centre Lathe
460mm swing x 1500mm centres x 80mm bore, Premium quality lathe.
POA
Excludes GST. Configuration and freight quoted with your enquiry.
NZ Prepared, installed and supported nationwide by Scott Machinery.
Swing over bed
460mm
Distance between centres
1500mm (2000 or 3000mm options)
Spindle bore
80mm
Speed range
20 - 1,600 rpm (16 steps)
NZ owned
Since 1989
Industry people
Practical machine advice
Auckland + Christchurch
Two support hubs
Nationwide support
Installation, training & service
Parts & accessories
Large local range
Product overview
About this machine.
460mm swing x 1500mm centres x 80mm bore, Premium quality lathe.
Quality Taiwanese Manufacturing
- Headstock spindle supported by two high grade taper roller precision bearings and a third high precision deep grove precision roller bearing.
- Spindle machined from forged alloy steel, hardened ground and dynamically balanced
- Gears are hardened and MAGG or Reishauer ground for extreme low hour noise levels
- Bed ways are induction hardened and precision ground
- Integrated automatic control for longitudinal and cross feeds, forward and reverse feeds
- Anti-float design backlash eliminator fitted in cross slide nut
- Camlock spindle with D1-8 nose
- Headstock clutches (using the original Matrix multiplate clutches)
- Automatic feed sensitive overload
- Turcite B coating between the bed and carriage
- Pressure lubrication system in headstock can ensure its lubrication and cooling when high speed cutting
- High degree of feel & sensitivity
3 Jaw "strong" Chuck 310mm "SC"
- B/plate D1-8
- 4 Jaw "Universal" Chuck Direct mount D1-8
- Face Plate
- Chuck Guard
- Tool post Guard
- Leadscrew Cover
- New style rear splash guard with light
- (old style shown)
- Rapid Italian style Quick change tool post B size c/w 4 holders
- D1-8 Spindle Nose
- Carriage micro stop set
- Steady rest with ball bearings (40mm - - 200mm)
- Travelling steady with bronze tips
- Coolant system
- Optional:
- 5c Collet Chuck and Collets
- Taper turning Attachment
- Newall DP1200 or Newall NMS 300 2 Axis
- DRO System
Published data
Specifications
Use these to shortlist. We’ll confirm the specification and configuration against the application.
Model
1860
Swing over bed
460mm
Swing over cross slide
280mm
Swing in gap
710mm
Spindle bore
80mm
Distance between centres
1500mm (2000 or 3000mm options)
Speed range
20 - 1,600 rpm (16 steps)
Tailstock taper
5MT
Motor
10 HP
Nett machine weight
2,350 kg
