Spiro Fittingshaper 1250
POA
SHET-0-5160 | Prices exclude GST
Product overview
About this machine.
The Fittingshaper contributes vitally to reduce the leakage rate in the ventilation system, resulting in reduced energy consumption costs!
The Fittingshaper is a flexible machine made for mounting rubber gaskets to fittings in small volumes but with many different sizes.
Combine the Fittingshaper 1250 & Spiro Shaper to achieve the full dimension range of rubber gasket on your fittings!
SPIRO offer the best in the business 2 year warranty.
Key features
- Makes it possible to obtain tightness class D also on large dimensions
- Complete set of tooling included, profiling wheels for 5 different gasket widths
- Powerful hydraulic system to ensure perfect result on all sheet thicknesses
- Easy adjustable table height and support rollers
- Fast and easy installation
- Factory fitted gasket without any loose parts
- Temperature resistant from -30˚C to +100˚C
- Withstands positive pressure - 3000Pa
Diameter range:
- 125 - 1250mm
Material:
- 0.5 to 0.9mm galvanized steel
- 0.5 to 0.8mm stainless steel
